AHB 80 • Profile Bender • Ring Roller • Hydraulic Dual Pinch • 80mm Shafts • NC Touchscreen

The AHB-80 Profile Bender Ring Roller is designed for high precision and efficiency in bending metal profiles and rings. It features an 80mm shaft diameter and a top roll diameter of 245mm, powered by a 5 kW motor and operating at 400V/50Hz. The machine's three driven rolls and bottom moveable rolls enhance its versatility, allowing it to handle various bending tasks. The Delta touch screen HMI ensures intuitive control, while the heavy-duty SR355 steel framework guarantees durability. Suitable for demanding industrial applications, the AHB-80 provides consistent and reliable bending performance.

Profile	Dimensions [mm]	Min. Bending Diameter [mm]
Equal Angle Leg Out	35 x 35 x 3 50 x 50 x 5	250 500
Equal Angle Leg In	30 x 30 x 3 40 x 40 x 5 50 x 50 x 6	400 600 1000
T-Section Leg Out	30 x 30 x 3 80 x 40 x 7.5	300 600
T-Section Leg In	30 x 30 x 3 50 x 50 x 6 70 x 35 x 6	300 600 1200
Flat Bar Hard Way	40 x 10 60 x 20 80 x 25	220 500 2100
Flat Bar Easy Way	50 x 5 80 x 16 80 x 20 15 30 40	200 400 1200 300 600 1400
Solid Bar	20 35 50 25 x 15 60 x 20 70 x 2	300 600 800 200 800 1600
Round Tube	26.5 x 2.3 48.3 x 2.9 60.3 x 3.2	200 600 1000
Rectangle Tube Hard Way	30 x 15 x 1.5 60 x 30 x 2.5 80 x 30 x 3	300 2000 6000
Rectangle Tube Easy Way	20 x 20 x 2 50 x 50 x 2.5 60 x 60 x 3	240 1600 4000
U Channel Leg Out	UNP 30 UNP 60 UNP 80	300 400 800
U Channel Leg In	UNP 30 UNP 60 UNP 80	300 500 1000

Profile Bender Capacity Chart
