ERLO V.10 – 12mm Compact Variator Drill Press for Precision Maintenance Work
ERLO V.10 – 12mm Compact Variator Drill Press for Precision Maintenance Work
12mm compact drill press with electronic variator speed control and manual feed for light-duty and precision tasks.
Purpose-built for small-format jobs, the ERLO V.10 offers variable-speed control through an electronic variator (250–3000 rpm) and manual feed blades. A B16 spindle and 60 mm drilling depth deliver consistent precision. The integrated drill guard with micro-switch, emergency stop, and adjustable depth stop ensure safety and reliability. Ideal for electronics assembly, maintenance benches, or training labs, the V.10 is CE-compliant and built on a durable fixed table.
Specifications
- Max Drilling Capacity [mm]: 12
- Continuous Drilling Capacity [mm]: 10
- Spindle Type: B16
- Spindle Stroke [mm]: 60
- Motor Power [kW]: 0.54
- Motor Voltage: 230V (Single Phase)
- Speed Range [rpm]: 250–3000
- Feed Type: Manual
- Spindle to Column Distance [mm]: 220
- Spindle to Table Distance [mm]: 105–245
- Spindle to Base Distance [mm]: 315
- Column Diameter [mm]: 70
- Table Dimensions [mm]: 300 × 250
- Machine Dimensions [mm]: 320 × 450 × 830
- Weight [kg]: 44
Features
- Compact design for maintenance and repair work
- Electronic variator for fine speed control
- Manual feed blades for sensitive drilling
- Drill guard with integrated micro-switch
- Emergency stop and low-voltage control panel
Options
- Fixed Drilling Depth Stop
- 80 mm Vice (0–120 mm opening)
- Fast-Action Precision Chuck B.16 (1–13 mm)
- Intermediate Table (For V.10/VT.10)
- Base Cabinet with Door and Drawer
Additional information
| Weight | 44 kg |
|---|---|
| Dimensions | 320 × 450 × 830 cm |
