Scantool 40BK AUT • Mill Drill Machine-Autofeed • Gear Driven • Drilling Capacity: 40 mm • Table 730 x 210 mm • MT4

Technical Specifications:

• RPM: 50 – 2500
• Voltage: 3x400V – 50Hz
• Motor Power: 1 HP (0.75 kW)
• Drilling Capacity: 40 mm
• Morse Taper: MT3
• Column Diameter: 115 mm
• Cross Table Size: 730 x 210 mm
• Distance Between Table & Spindle: 470 mm
• Throat Depth: 260 mm
• Number of Spindle Speeds: 12
• Speed Numbers – Motor: 2
• Automatic Feed: Yes
• Reversible: Yes
• Bench Model: Yes
• Height: 1960 mm
• Net Weight: 300 kg

Features and Uses:

• Geared head type for precise operations
• Automatic feed for enhanced productivity
• Sturdy construction ensuring durability
• Noiseless operation for a better working environment
• Tilting head for versatile positioning
• 2-speed motor with 12 spindle speeds for varied tasks
• Reversible function for operational flexibility
• Quick delivery and competitive pricing

Industries Using this Machine and Their Uses:

• Metalworking Shops: Precision drilling and milling
• Manufacturing Plants: Heavy-duty milling operations
• Educational Institutions: Teaching tool for machining
• Maintenance Departments: Repair and fabrication tasks
