Four Column Press • 300 Ton • RHTC
Four Column Press • 300 Ton • RHTC
Please contact for prices
The 300 Ton Four Column Hydraulic Press offers precision deep-drawing, metal forming, and heavy-duty pressing. European-made, CE-certified, and highly durable.
The Profi Press PPFC-300 is engineered to handle demanding industrial applications with precision and efficiency.
Key Benefits:
- Perfect Parallelism: Four cylindrical columns maintain precise alignment of the upper table.
- Advanced NC Control: Set parameters such as pressure, stroke, and speed digitally, and save up to 100 working cycles.
- Durable Construction: Built from robust S355JR steel and equipped with premium European components.
- CE Compliance: Designed to meet the latest safety and quality regulations.
- Customizable Options: Adaptable for larger piston strokes, larger tables, or other specific requirements.
Technical Specifications
- Force: 300 tons
- Motor Power: 11 kW
- Working Speed: 3.2 mm/sec
- Approaching Speed: 11.3 mm/sec
- Return Speed: 16.6 mm/sec
- Piston Stroke: 460 mm
- Column Diameter: 150 mm
- Table Size: 1860 x 1200 mm
- Between Columns: 1320 x 660 mm
- Vertical Light: 820 mm
- Working Height: 850 mm
- Total Length (Lateral): 1700 mm
- Total Width (Frontal): 2420 mm
- Overall Height: 2900 mm
- Weight: 13,000 kg
Key Features
- Rigid and robust machine frame, made out of S355JR steel
- Upper- and lower table with T-grooves
- Four cylindrical columns for perfect parallelism
- Digital setting and saving of the parameters
- Selector for manual, semi-automatic, or automatic mode
- Selector for working with 1 or 2 speeds
Optional Accessories
- A frontal sliding lower table
- Adaptations to robotics
- Hydraulic connections for peripheral systems
- Higher speeds by prefilling valves and auxiliary cylinders
- Hydraulic cushion or ejector
- Cooling equipment for the hydraulic group by an air-oil cooling system
PPFC-300 Dimensions
- A – Footprint – Side: 1200 mm
- B – Footprint – Front: 1860 mm
- C – Useful Area – Side: 660 mm
- D – Useful Area – Front: 1320 mm
- V – Vertical Daylight: 820 mm
- F – Working Height: 850 mm
- L – Depth Front to Back: 1700 mm
- W – Width Left to Right: 2420 mm
- H – Overall Height: 2900 mm
RHTC Four Column Hydraulic Press with side-mounted power pack.,
Additional information
| Weight | 10800 kg |
|---|---|
| Dimensions | 1500 × 2650 × 3250 cm |
